Aluminum MIM Material Properties 6061
6061 alloy is one of the most popular forging alloy grades, renowned for its excellent ductility, extrudability, weldability, machinability, thermal conductivity, electrical conductivity, and corrosion resistance. 6061MIM material composition and its properties introduction:
| MIM 6061 | Sintered | T6 | bar and sheet metal |
|---|---|---|---|
| Density(g/cm²) | 2.68±0.01 | 2.68±0.01 | 2.70-2.73 |
| Vickers hardness(HV) | 50±5 | 105±5 | 86-110 |
| Yield strength(MPa) | 78 | 296 | 55-245 |
| Tensile strength(MPa) | 158 | 335 | 124-265 |
| Elongation( %) | 26 | 6 | 25/8 |
| Electrical conductivity(IACS) | 41.9 | 47/43 | |
| Thermal conductivity W/(m²K) | 136 | 18C | |
| Mirror polishing | OK | OK | OK |
| Salt spray test | 48h | OK | |
| PVD | OK | OK | OK |
| Anodizing | OK | OK | OK |
